Good for
PS1, Genesis, GBA, SNES
Support listed to
Dreamcast
OS
Linux
Custom firmware
muOS, Knulli
Released
Jul 2024
Where to buy
The RG40XXH is a budget horizontal retro handheld from Anbernic with a 4.0-inch 640×480 IPS screen, WiFi and Bluetooth, and runs Linux. It is best suited for PS1, Genesis, GBA, SNES, with support listed up to Dreamcast. It typically sells for around $70.
Played on the Anbernic RG40XXH
1 player has logged 31 sessions and 39 hours on this handheld.
2 sessions this month · 2 new owners
Emulation
Supports 12 of 18 tested systems: 6 at excellent, 3 running well.
Mid-generation systems
Mixed5 of 5 systems listed as playable or better
Modern systems
Unsupported0 of 4 systems listed as playable or better
Classic systems
Excellent6 of 6 systems listed as playable or better
Sixth-generation systems
Limited1 of 3 systems listed as playable or better
Emulation source notes
- DS: Nintendo DS: Most games playable at full speed, a few games have lower frame rates but still mostly playable with frameskip This device does not have a touchscreen, so you won't be able to play DS games that rely heavily on the touchscreen
- 3DS: Nintendo 3DS: Either cannot run any games at all or games are unplayably slow
- GBA: Nintendo Game Boy Advance: Almost all games playable at full speed without frameskip
- N64: Nintendo 64: Most games playable at full speed, a few games have lower frame rates but still mostly playable with frameskip
- NES: Nintendo Entertainment System: Almost all games playable at full speed without frameskip
- PS1: Sony Playstation: All games playable at full speed without frameskip
- PS2: Sony Playstation 2: Either cannot run any games at all or games are unplayably slow
- PS3: Sony Playstation 3: Either cannot run any games at all or games are unplayably slow
- PSP: Sony Playstation Portable: Most games playable but mostly with frameskip, struggles with harder to emulate games
- Wii: Nintendo Wii: Either cannot run any games at all or games are unplayably slow
- SNES: Super Nintendo Entertainment System: Almost all games playable at full speed without frameskip
- Wii U: Nintendo Wii U: Either cannot run any games at all or games are unplayably slow
- Saturn: Sega Saturn: Most games playable but mostly with frameskip, struggles with harder to emulate games
- Switch: Nintendo Switch: Either cannot run any games at all or games are unplayably slow
- Genesis: Sega Genesis / Mega Drive: Almost all games playable at full speed without frameskip
- Game Boy: Game Boy / Game Boy Color: Almost all games playable at full speed without frameskip
- GameCube: Nintendo GameCube: Only the easiest to emulate games are barely playable
- Dreamcast: Sega Dreamcast: Most games playable at full speed, a few games have lower frame rates but still mostly playable with frameskip
Specifications
Display
Screen
4.0 inch
Aspect ratio
4:3
Resolution
640 x 480
Pixel density
200 PPI
Panel
IPS
Refresh rate
60 Hz
Performance
Chipset
Allwinner H700
CPU
Cortex-A53
CPU clock
1.5 GHz
CPU cores
4
CPU threads
4
GPU
Mali-G31 MP2
GPU clock
650 MHz
RAM
1 GB LPDDR4
Storage
Dual External MicroSD
Architecture
ARM
Build
Battery
3200 mAh
Battery life
6 hours
Weight
208 grams
Dimensions
163 mm x 79 mm x 16 mm
Material
Plastic
Charge port
USB-C
Controls
Shoulder buttons
Stacked
D-pad
Top
Thumbsticks
Symmetrical
Extra buttons
Menu, Power, Reset, Volume +-
Features
FAQ
- What systems can the Anbernic RG40XXH emulate?
- The Anbernic RG40XXH plays systems up to Dreamcast well. It is at its best with PS1, Genesis, GBA, SNES.
- Can the Anbernic RG40XXH play Dreamcast games?
- Yes. Dreamcast performance on the Anbernic RG40XXH is rated good in our catalog. Sega Dreamcast: Most games playable at full speed, a few games have lower frame rates but still mostly playable with frameskip
- Can the Anbernic RG40XXH play Saturn games?
- Only partially. Saturn on the Anbernic RG40XXH is playable with compromises. Sega Saturn: Most games playable but mostly with frameskip, struggles with harder to emulate games
- How much does the Anbernic RG40XXH cost?
- The Anbernic RG40XXH typically sells for around $70, which puts it in the budget tier of retro handhelds.
- What operating system does the Anbernic RG40XXH run?
- The Anbernic RG40XXH ships with Linux and also supports muOS, Knulli.
- What screen does the Anbernic RG40XXH have?
- It has a 4.0 inch IPS display with a 4:3 aspect ratio, running at 640 x 480 at 200 PPI.
